D28*H30
Product Description



SpecificationDiameterThicknessD.C. reference voltage (U1mA)Leakage current under 75%U1mA Max. ratio of residual voltage    (8/20us)Current impulse withstand capabilityRecommended rated voltage  Maximum energy absorption capacity        Recommended continuous operating voltage
4/10us 2ms
mmmmkVuAat 5kAkAAkVkJ/kVrkV
MOV28×2028±0.520±0.54.0-4.8<101.856012031.052.4
MOV28×2428±0.524±0.55.0-5.8<101.85601203.81.053
MOV28×3028±0.530±0.56.2-7.0<101.85601204.51.053.6
MOV30×330±0.53.0±0.50.6-0.8<101.83401500.280.80.22
MOV30×630±0.56.0±0.51.2-1.6<101.83401500.50.80.4
MOV30×2030±0.520±0.54.0-4.8<101.836515031.292.4
MOV30×2430±0.524±0.55.0-5.8<101.82651503.81.293
MOV30×3030±0.530±0.56.2-7.0<101.82651504.51.293.6
MOV32×2032±0.520±0.54.0-4.8<101.756520031.632.4
MOV32×2432±0.524±0.55.0-5.8<101.75652003.81.633
MOV32×3032±0.530±0.56.2-7.0<101.75652004.51.633.6
MOV35×335±0.53.0±0.50.6-0.8<101.73402500.281.240.22
MOV35×635±0.56.0±0.51.2-1.6<101.73402500.51.240.4
MOV35×2035±0.520±0.54.0-4.8<101.736525032.012.4
MOV35×2435±0.524±0.55.0-5.8<101.73652503.82.013
MOV35×3035±0.530±0.56.2-7.0<101.73652504.52.013.6

 Product features:

  2 spray granulator

  40m the longest kiln in China

  Certification: ISO9001 &amp; 14001 &amp; CQC, etc

  Fine all aluminum electrode

  Over voltage and high current withstand capacity

  Low leakage current (under continuous operating voltage)

  High quality nonlinear characteristics

  Comply with GB / IEC / IEEE and other standards

  Resistor can be connected in series flexibly

  Resistor 100% fully aged
